Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling

Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling

  • Application
    General Pneumatics
  • Nominal
    1/4
  • Name
    Safety Coupling
  • Pressure
    232psi
  • Size
    1/4",3/8
  • Shape
    Reducing
  • Material
    Aluminum
  • Type
    Fittings
  • Place of Origin
    Shanghai, China
  • Brand Name
    carterberg
  • Certification
    IATF16949
  • Model Number
    CB-12
  • Minimum Order Quantity
    Negotiation
  • Price
    Negotiation
  • Packaging Details
    carton
  • Delivery Time
    7-20 work days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union
  • Supply Ability
    5000~20000 pc/month

Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling

Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling



CB-12 Series Industrial Interchange pushbutton safety coupling is designed for use with compressed air.



Standard Materials

  • Aluminum
  • Seals: NBR, Viton, EPDM

Features

  1. Safe and easy to connect and disconnect. Two-step disconnect procedure shuts off air supply and releases downstream air pressure before plug can be removed from socket. Hose whip is prevented.
  2. Light weight, compact ergonomic design
  3. Compatible with Hansen SAFELINE Series



Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling 0



Body Size PARTNO. Thread A B HEX
1/4" CB-S2S-12MN-F 1/4-18 3.18 1.02 0.67
1/4" CB-S3S-12MN-F 3/8-18 3.18 1.02 0.75

Industrial Interchange pushbutton safety coupling is designed for use with compressed air Pneumatic Quick Coupling 1

Body Size PARTNO. Thread C D HEX
1/4" CB-P1S-12MN 1/8-27 1.59 0.58 0.50
1/4" CB-P2S-12MN 1/4-18 1.75 0.65 0.56
1/4" CB-P3S-12MN 3/8-18 1.75 0.79 0.69
1/4" CB-P2B-12MN 1/4-18 1.75 0.64 0.56
1/4" CB-P2L-12MN 1/4-18 1.75 0.65 0.56
