Compressed Air 103 Bar Brass Pneumatic Quick Coupling

Compressed Air 103 Bar Brass Pneumatic Quick Coupling

  • High Light

    IATF 16949 Pneumatic Quick Coupling

    ,

    0.25in Pneumatic Quick Coupling

    ,

    Brass quick release air hose connector

  • Application
    General Pnuematics
  • Size
    1/4
  • Pressure
    103bar
  • Material
    Brass
  • Type
    Coupling
  • Thread
    Male
  • Name
    Quick Coupling
  • Process
    Punching
  • Place of Origin
    Shanghai, China
  • Brand Name
    carterberg
  • Certification
    IATF16949
  • Model Number
    CB-12
  • Minimum Order Quantity
    Negotiation
  • Price
    Negotiation
  • Packaging Details
    carton
  • Delivery Time
    7-20 work days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union
  • Supply Ability
    5000~20000 pc/month

Compressed Air 103 Bar Brass Pneumatic Quick Coupling

Designed for use with compressed air and other gases Brass Pneumatic Quick Coupling



CB-12 Series quick connect couplings are designed for use in acetylene service. The Series can also be used with compressed air and other gases.





Features

  1. Safety sleeve lock prevents accidental disconnections
  2. Non-Interchangeable design prevents crossing of lines
  3. Designed for use with compressed air and other gases
  4. OSHA compliant
  5. Standard body material: Brass
  6. Standard seal material: Buna-N
  7. Compatible with Hansen 700 Series

Compressed Air 103 Bar Brass Pneumatic Quick Coupling 0



Body Size PARTNO. Thread A B HEX
1/4" CB-S1B-12MN-J 1/8-27 1.94 1.00 0.69
1/4" CB-S2B-12MN-J 1/4-18 2.09 1.00 0.69
1/4" CB-S3B-12MN-J 3/8-18 2.09 1.00 0.69

Compressed Air 103 Bar Brass Pneumatic Quick Coupling 1

Body Size PARTNO. Thread C D HEX
1/4" CB-P1B-12MN-J 1/8-27 1.41 0.63 0.56
1/4" CB-P2B-12MN-J 1/4-18 1.56 0.63 0.56
